caizer f50+ 5.0t 4 post hoist
FEATURES
- 5000kg SWL 4-Post Hoist
- 1840mm Lifting Height
- Control post LHF or RHR Installation
- Adjustable width platform
- 4-Point Electric Safety Locks
- 4-Point Wire Rope Failure Safety Locks
- 8-Point Crossbeam Stabiliser Brackets
- LED Lift Cycle Counter Display
- Lockable Isolator & Emergency Stop
- Optional: Bolt-on wheel alignment platform kit
- Optional 2500kg jacking bridges
SPECIFICATIONS
Model : Caizer F50+Safe Working Load : Main Lift: 5000kg / Jack: 2500kgMax. Lifting Height : Main Lift: 1840 / Jack 455mmMin. Height : F50 174mm / F50A 234mmLifting Time : Main Lift: 30~50sec / Jack: 5~15secLowering Time : Main Lift: 30~50sec / Jack: 5~15secMotor : 3ph 2.2kw 415V 50HZOperating Method : Control Box, Cable Remote ControlWeight : F50 1700KG / F50A 2000kg
